4 Receiver Transmitter - 4 Radio Control Equipment V2 Rack (4RTR-4RCE-V2-8D)
Engineering Drawings (PDF)
RACK LAYOUT, SCHEMATICS & PUNCHDOWN (7 SHEETS)
4 Receiver Transmitter - 4 Radio Control Equipment V2 Rack (4RTR-4RCE-V2-8D)
SPECIFICATIONS:
Dimensions (OD): 83" (H)x 22" +-1/4" (W) x 25.5" (D)
Approx. Weight: 300lbs. (Bare rack excl. eqp.)
| T1 TX/RX# A (1,2) | T2 TX/RX# A (3,4) | T3 Blank |
