16RX MC 2381 Rack Configuration

NSN: 8200-00-003-2381-1


Part Number # RCA-2381


16 Receiver w/  Multicouplers V2 Rack (16RX-MC-V2-8S)

Engineering Drawings (PDF)

RACK LAYOUT, SCHEMATICS & PUNCHDOWN

16 Receiver w/ Multicouplers V2 Rack (16RX-MC-V2-8S)

Engineering Drawings (DGN)

RACK LAYOUT, SCHEMATICS & PUNCHDOWN

SPECIFICATIONS:

Dimensions (OD): 83" (H) x 22" +-1/4"(W) x 22" (D)

Approx. Weight: 300lbs. (Bare rack excl. eqp.)

RX#
A (1,2,3,4)
D (5,6,7,8)
RX# A(9,10,11,12)
D(13,14,15,16)
T3 Blank
