4RTR 2386 Rack Configuration

NSN: 8200-00-003-2386-1


Part Number # RCA-2386


4 Receiver Transmitter V2 Rack (4RTR-V2-8S)

Engineering Drawings (PDF)

RACK LAYOUT, SCHEMATICS & PUNCHDOWN

4 Receiver Transmitter V2 Rack (4RTR-V2-8S)

Engineering Drawings (DGN)

RACK LAYOUT, SCHEMATICS & PUNCHDOWN

 SPECIFICATIONS:

Dimensions (OD): 83" (H) x 22" (W) x 22" (D)
Approx. Weight: 300lbs. (Bare rack excl. eqp.)

T1 TX/RX#
A (1,2)
T2 TX/RX# A(3,4)
T3 Blank
